Description
Description
ZYPOLISH FC134 diamond lapping films are produced by using the latest ultra-precision coating technology. Precisely graded diamond minerals are coated on a high strength polyester film. FC134 is especially suitable for precision polishing of fiber ceramic ferrules,glass ferrules, gemstones, stainless steel, metal,semiconducting materials, etc.
Advantage
1. Uniform and consistent finish.
2. Perfect grinding efficiency.
3. High polishing accuracy.
4. Suitable for polishing with dry, water or oil.
|
Product Name |
FC134 Diamond Lapping Film |
|||
|
Product Type |
FC134-1, FC134-3,FC134-6, FC134-9,FC134-15,FC134-30,FC134-45,FC134-60 |
|||
|
Mineral |
Diamond |
|||
|
Grit |
60/45/30/15/9/6/3/1/0.5/0.3/0.1 micron |
|||
|
10000/8000/5000/3000/2500/2000/1500/1000/600/320/240# |
||||
|
Round Size |
Φ127mm(5inch), Φ152mm(6inch),Φ203mm(8inch), customizable |
|||
|
Square Size |
152mm×152mm(6inch), 203mm×203mm(8inch), customizable |
|||
|
Backing |
PET, PSA or Velcro |
|||
|
PET Thickness |
3mil(75μm), 5mil(125μm) |
|||
|
Specification |
φ32mm or Daisy φ35mm, Customizable size |
|||
Details
Application
Precision polishing for ceramic ferrules，gemstones，metal，etc.
